Dimensions: 2-3/8"W x 2-3/8"D x 3-3/4"H
SKU |
XR-2151-12V |
XR-2151-36V |
XR-2151-48V |
Current Rating |
200 amps |
200 amps |
200 amps |
Max Flash Current |
300 amps |
300 amps |
300 amps |
Work Specification |
Continuous |
Continuous |
Continuous |
Contact Form |
1NO |
1NO |
1NO |
Voltage |
12VDC |
36VDC |
148DC |
Replace Number |
|
E-Z-GO 20468G1, Trombetta 114-3611-020 White Rodgers: 586-117111 586-117111-3 586-906S1 586-906 Club Car 1016072 Columbia 71458-87 Yamaha JF3-H1950-00 PRESTOLITE 15-552 SBJ4301 JOHNSON ELECTRIC 5122340 SO51223 Miscellaneous Vendor 586-117111-5 6C026 MELEX 510204 TAYLOR-DUNN 72-501-38 |
586-120111 101883601 1018836-01 73231G01 73231-G01 JR1-H1950-00 |
Application |
|
Fit Models Club Car DS, Electric, 1988-2005, Columbia Electric 1987 and newer, E-Z-GO electric, 1989 and newer, Yamaha Electric G4, G8, G9, G11 and G16 |
1995-present Yamaha G19 & G22 Electric Golf Carts and 1995-1999 Club Car Electric Golf Carts/ E-Z-GO Shuttle 2 to 6 passenger series 950 series Titan and XI-875 electric 1995 and newer /Compatible with Yamaha Electric 48 volt G19 Golf Cart JR1-H1950-00 Motrec 486222 |
The first step is to install the battery isolation relay on the linear purification valve mounting tab of the double battery tray, if not, you can also choose to install it in a flat place.
The second step is to connect the red long battery jumper on the relay to the positive pole of the main battery, and at the same time use the socket wrench and terminal on the isolation relay.
In the third step, connect the red short battery jumper and the switch isolator relay wire with a large ring terminal to the terminals on the isolator relay, respectively.
In the fourth step, connect the small ring terminal of the switch isolator relay wire with the positive terminal of the isolator relay.
The isolator relay ground wire and negative terminal are then connected together by a socket wrench and grounded in the engine compartment.
Finished. This battery isolator relay is suitable for use where multiple batteries are required
